Elmo TT-12, 3.4mp, 96x, 1080i Document Camera

The Elmo TT-12 Document Camera connects to a Mac or PC -- and to a projector and offers two categories of use. It lets users apply features, such as picture-in-picture, to material being projected onto a wall, and it allows sessions to be captured in high-definition video that can be posted later.

The features applicable are part of software called Image Mate that comes included with the camera. In addition to picture-in-picture, Image Mate offers split-screen, highlights, masks, color filters, Mosaic, and an annotation tool that works by mouse. For normal projection, class documents need only be placed under the camera eye. But for projection with a feature applied, in addition to what's under the camera eye, images separately captured can be incorporated, as they would be in picture-in-picture.

The camera has a 3.4 megapixel CMOS sensor that captures bright and colorful video and photos, and an internal mic that records sound. A jack for an external mic is also available. Shots can be gotten from almost any angle per a swivel-adjustable arm, and, by the combination of a 12x optical zoom and an 8x digital zoom, details can be magnified by 96 times without any distortion. Focus can be set manually or set automatically at the tap of a button. Files can be saved to a connected computer or internally via USB/SD/SDHC slots. Output is by HDMI out and audio line out, and is at 30 frames-per-second and thus in smooth, full-motion video. Different output resolutions up to 1080p HD can be selected at the flip of a switch.

For control, a control panel and a remote control are included. However, the camera is compatible with ELMO's CRA-1 wireless tablet that if incorporated would replace not only the control panel and remote control but also a connected computer.

PRODUCT HIGHLIGHTS:

Live Projection and Video Capture:

• Connects to a projector and to a computer (Mac / PC)

• Enhances projected material with features like split-screen

• Captures class sessions to be posted online for students/parents

• Saves files to computer or internally via USB/SD/SDHC memory slots

High-Quality Images and Audio:

• A 300° swivel adjustable arm allows shots from almost any angle

• A 3.4 megapixel CMOS sensor captures bright and colorful video/photos

• A built-in mic records sound, and a jack is available for use of an external mic

• Outputs smooth, full-motion video at 30 fps in up to 1080p HD by HDMI/audio out

• A 12x optical and an 8x digital zoom combine to offer distortion-free 96x magnification

Manufacturer

Brand	Elmo
Model	TT-12

General

Type	Document Camera
Color	White

Optics

Lens	F3.2 - 3.6 f=4.0 mm - 48.0 mm
Optical Sensor	1/2.8" CMOS 3,400,000 pixels 30 fps
Native Resolution	Total Pixels: 2,144 (H) x 1,588 (V) Effective Pixels: 1,920 (H) x 1,536 (V) Analog RGB: 800 (H) x 800 (V) TV lines or more Video output: 500 (H) TV lines or more
White Balance	Auto / One-Push / Manual
Zoom	12X optical (Auto / Manual), 8x digital zoom

Connectivity

Input Connectors	1 x RGB input mini D-sub 15-pin connector (female) 1 x 3.5 mm-diameter stereo mini jack
Output Connectors	1 x RGB output mini D-sub 15-pin connector (female) 1 x Composite video output RCA pin jack 1 x (NTSC/PAL) HDMI output terminal 1 x 3.5 mm-diameter stereo mini jack

Supported Formats

Output Formats

Analog RGB: 1080p: 1,920 x 1,080 @ 60 Hz 720p: 1,280 x 720 @ 60 Hz SXGA: 1,280 x 1,024 @ 60 Hz WXGA: 1,280 x 800 @ 60 Hz XGA: 1,024 x 768 @ 60 Hz HDMI: Image output: 1080p/720p Audio output: PCM 44.1 kHz sampling frequency

Physical Information

User Controls	USB device (2.0 compliant) Mini-B receptacle x 1
Power	12V DC (AC adapter AC 100-240V)
Dimensions (WHD)	Setup: 14 x 14.68 x 16.81 inches Folded: 7.68 x 11.56 x 18.43 inches
Weight	7.1 lbs
Illumination System	White LED lamp
Construction	ABS Plastic

Special Features

Features

* Edge enhancement * Still image & movie storage * Support functions: Highlight, Mask, Scroll (in digital zoom), Mosaic, Split screen, PinP (Picture-in-Picture), Color filter, Microscope, Image rotation (0°/180°), Positive/negative conversion, Color/B&W selection.
