Shure ULXD4Q-G50 Quad Channel Digital Wireless Microphone System
Rentals starting at
$300.00
Rent-A-Bit low price guarantee!
Call us or click below to request a quote.
The Shure UHF-R Professional Diversity Wireless Microphone System reinforces Shure's status as leaders in large-scale touring and fixed installation wireless microphone systems. The UHF-R series is primarily designed for touring, stage performances, fixed installation in large clubs, theaters, houses-of-worship, large scale presentations and more.
PRODUCT HIGHLIGHTS:
- J5 / 578-608, 614-638MHz
- UR4D+ Dual Diversity Receiver
- UR1 Bodypack Transmitter x2
- Simultaneous Dual Transmitter Operation
- 2400 Selectable Frequencies
- Automatic Transmitter Setup
- Switchable RF Power
- 2x AA Battery Power for 9 Hours
Manufacturer
| Brand | Shure |
| Model | ULXD4Q-G50 |
General
| Type | UHF |
| Color | Black |
| Construction | Galvanized Steel |
Receiver Connectivity
| Output Connectors | 1 x XLR connector (into 600 Ω load) 1x 6.35 mm (1/4") connector (into 3 kΩ load) |
Receiver Performance Data
| Frequency Response | 25 Hz – 15 kHz, ±2 dB Note: Dependent on microphone type |
| UHF Band | Available options in stock: G3E (470-506 MHz) J2 (554-590 MHz) K2E (606-642 MHz) M2 (662-698 MHz) R4 (784-820 MHz) S3 (829-865 MHz) Q2 (748-784 MHz) |
| Operating Range (FT) | 100 m (300 ft) typical Note: Actual range depends on RF signal absorption, reflection and interference. |
Receiver Physical Information
| User Controls | Scan and sync® instantly and automatically sets up the system |
| Power | 14–18 V DC (negative ground), 550 mA |
| Dimensions (WHD) | 43 x 214 x 163 mm (1.72 x 8.56 x 6.52 in.), H x W x D |
| Weight | 1049 g (2 lbs, 5 oz.) |
Body Pack Transmitter
| RF Output (mW) | 1-20 mW |
| Gain Adjustment | 20 dB |
| Polar Pattern | WL185 (super cardioid) |
| Battery Type/Life | 2 x "AA" size alkaline batteries / up to 11 hours |
| Dimensions (WHD) | 2.6" x 3.4" x 0.9" |
| Weight | 5.0 oz |
Handheld Transmitter
| RF Output (mW) | 1-20 mW |
| Gain Adjustment | 20 dB |
| Polar Pattern | SM58 (cardioid) |
| Battery Type/Life | 2 x "AA" size alkaline batteries / up to 11 hours |
| Dimensions (WHD) | 10.1" x 2.0" |
| Weight | 12.0 oz |
Patch Cables
- XLR Balanced Audio Patch Cable (M-F)
Audio Components
- Shure UA874US Active Directional Antenna (470-698 MHz)
- Shure UA844SWB Antenna / Power Distribution System (470-952 MHz)
- Shure UA221 Passive Antenna Splitter
- JTS CM-8015F Lightweight Single Ear Hook Microphone (Beige)
- Shure WL185 Lavalier Condenser Microphone
- Universal Microphone Clip for Vocal Microphones
- Shure WL93 Lavalier Condenser Microphone
- Voice Technologies VT600T IFB Earphone w/ Coiled Trans. Tube - Beige
- Shure ULXD1 Wireless Bodypack Transmitter w/ Shure WL185 Lavalier Microphone
- Shure ULXD2/SM58-Wireless Hand-Held Microphone Transmitter
Consumables
- Procell™ AA Alkaline Battery
